The Additive Manufacturing Galaxy
Polyjet Stratasys®
Hundreds of possibilities
Flawless surface finish
Overmolding simulation
The only solution for simulating rubber overmolding on rigid components. (e.g., handpieces, electronic devices).
Lifelike models
Unleash your creativity and print multicolour models for demonstration purposes straight from ASSEMBLY CAD and 3D VRML files, with no painting required.
High surface quality
Polyjet enables the manufacture of surfaces that convey the exact feel of the finished product, even in the case of complex shapes and intricate details.
Biocompatible materials
Biocompatible materials allow the production of models on which invisible aligners, guides and other surgical preparatory elements can be thermoformed.
Technical Data
| Materials | RIGUR RGD450 |
FULLCURE RGD720 |
VERO FAMILY |
RUBBER FAMILY |
|
|---|---|---|---|---|---|
| Tensile strenght MPa | Metodo ASTM D638-03 | 40-45 | 50-56 | 50-65 | 0.8-5 |
| Elongation at break % | Metodo ASTM D638-05 | 20-35 | 15-25 | 10-25 | 45-240 |
| Modulus of elasticity MPa | Metodo ASTM D638-04 | 1700-2100 | 2000-3000 | 2000-3000 | N.A. |
| Flexural Strenght MPa | Metodo ASTM D790-03 | 52-59 | 80-110 | 75-110 | N.A. |
| Flexural Modulus MPa | Metodo ASTM D790-04 | 1500-1700 | 2700-3300 | 2200-3200 | N.A. |
| Shore Hardness | Metodo ASTM Scale D | 80-84 D | 83-86 D | 83-86 D | 26-77 A |
| Izod Notched Impact J/m | Metodo ASTM D256-06 | 30-35 | 20-30 | 20-30 | N.A. |
| Heat Deflection Temp °C @ 0,45 MPa | Metodo ASTM D648-06 | 49-54 | 45-50 | 45-50 | N.A. |
| Tg °C | Metodo DMA, E>> | 48-52 | 48-50 | 52-54 | N.A. |
| Polymerized density g/cm3 | Metodo ASTM D792 | 1.20-1.21 | 1.18-1.19 | 1.17-1.18 | 1.12-1.17 |
| Ash content % | Metodo ASTM USP281 | 0.3-0.4 | 0.01-0.02 | 0.01-0.02 | N.A |
| Apperance | Ivory | Natural | Multicolor | Gray Scale |
